Emulating Photoshop's blending modes

Seymour Clufley · Post by **Seymour Clufley** » Sat Feb 07, 2009 10:27 am

I'm in the middle of making a rather fancy video processor with FFMpeg and ImageMagick. The latter has some impressive drawing functions but where I need full control I'm using PB's internal commands.

One job involves overlaying one graphic onto another using - hopefully - an emulation of Photoshop's Color Dodge. Luckily I've found this page with algorithms for emulating Photoshop's mixing modes. It's missing a few that require HSL<>RGB conversion but here's Color Dodge, for the Green channel:

Code: Select all

GNew = GTop >= 255? 255 : min(GBottom * 255 / (255 - GTop), 255)

Can anyone tell me what is signified by the question mark, the colon, and "min"? This would be a great help.

And what does "GTop >= 255" mean?

Thanks for reading,
Seymour.

IceSoft · Post by **IceSoft** » Sat Feb 07, 2009 10:55 am

Code: Select all

If  GTop >= 255
GNew = 255
else
 GNew =min(GBottom * 255 / (255 - GTop), 255)
endif

Seymour Clufley · Post by **Seymour Clufley** » Sat Feb 07, 2009 10:58 am

Thanks very much, IceSoft! I'll go and test it right now!

By the way, what language is the original code in? Is it C?

IceSoft · Post by **IceSoft** » Sat Feb 07, 2009 11:02 am

Seymour Clufley wrote:Thanks very much, IceSoft! I'll go and test it right now!

By the way, what language is the original code in? Is it C?

Seems to be C /C++

BTW:
This will not work on PB (min(...,...) is not a PB function

Code: Select all

min(GBottom * 255 / (255 - GTop), 255)

Psychophanta · Post by **Psychophanta** » Sat Feb 07, 2009 11:05 am

Can be used something like:

Code: Select all

Procedure.l min(a.l,b.l)
  If a>b:ProcedureReturn b:EndIf
  ProcedureReturn a
EndProcedure

Seymour Clufley · Post by **Seymour Clufley** » Sat Feb 07, 2009 11:34 am

Yes, I guessed it stood for "minimum".

Thanks to both of you for your help here.

Now I'll see if I can translate all the other mixing modes by myself!

Seymour Clufley · Post by **Seymour Clufley** » Sat Feb 07, 2009 9:01 pm

Below is code that successfully emulates most of Photoshop's blending modes.

First the good news...

The following Photoshop modes seem to work:

Add (Linear Dodge)
Multiply
Screen
Overlay
Hard Light
Color Burn
Color Dodge
Linear Burn
Darken
Lighten
Difference
Exclusion
Vivid Light
Pin Light
Hard Mix

There are some non-Photoshop modes included which all seem to work as the original author (Jens Gruschel) demonstrates on his site.

Reflect
Glow
Phoenix
Negation
Average
Subtract
Freeze
Stamp

Now the bad news... The following Photoshop modes don't seem to work:

Hue
Saturation
Color
Luminosity
Linear Light
Soft Light

The first four rely on working in the HSL space - perhaps the error is in the conversion in or out of that.

LinearLight and SoftLight don't use HSL. I just can't get the calculations right. Three SoftLight procedures are included (each using a different algorithm) along with a LinearLight procedure. If anyone wants to work on these or the modes using HSL, please do.

And here's the code:

Code: Select all

;- START
;{
UseJPEGImageDecoder()


Procedure R(str.s)
  MessageRequester("Report",str,0)
EndProcedure

Procedure.d Beat(a.d,b.d)

  If a>b
      ProcedureReturn a
  Else
      ProcedureReturn b
  EndIf

EndProcedure


Procedure.d Defeat(a.d,b.d)

  If a<b
      ProcedureReturn a
  Else
      ProcedureReturn b
  EndIf

EndProcedure


Procedure.d Difference(a.d,b.d)

  If a=b
      ProcedureReturn 0
  EndIf

  ProcedureReturn Beat(a,b)-Defeat(a,b)

EndProcedure



Procedure ReportImage(img.i,free.b)

  If Not IsImage(img)
      ProcedureReturn R("img is not an image!")
  EndIf

  iw = ImageWidth(img)
  ih = ImageHeight(img)

  win = OpenWindow(#PB_Any,0,0,iw,ih,"Report Image",#PB_Window_BorderLess|#PB_Window_ScreenCentered)

  imgad = ImageGadget(#PB_Any,0,0,iw,ih,ImageID(img))

  escapekey = 1
  spacekey = 2
  returnkey = 3
  AddKeyboardShortcut(win,#PB_Shortcut_Escape,escapekey)
  AddKeyboardShortcut(win,#PB_Shortcut_Space,spacekey)
  AddKeyboardShortcut(win,#PB_Shortcut_Return,returnkey)

  Repeat
      we = WindowEvent()
      If we
          If we=#PB_Event_Menu
              Break
          EndIf
      Else
          Delay(10)
      EndIf
  ForEver

  CloseWindow(win)

  If free
      FreeImage(img)
  EndIf

EndProcedure


#RGBFull = 255
#IWMax = 2000
#IHMax = 2000


Enumeration ; mixing modes
  #Normal
  #Add
  #Multiply
  #Screen
  #Overlay
  #SoftLight
  #HardLight
  #ColorBurn
  #LinearBurn
  #ColorDodge
  #LinearDodge
  #Darken
  #Lighten
  #Difference
  #Exclusion
  #LinearLight
  #PinLight
  #VividLight
  #HardMix
  #Hue
  #Saturation
  #Color
  #Luminosity

  #Average
  #Negation
  #Subtract
  #Reflect
  #Glow
  #Phoenix
  #Stamp
  #Freeze
EndEnumeration


;}


Structure xArray
  yPoint.i[#IHMax]
EndStructure
Structure imageryinfo
  img.i
  pixeltable.xArray[#IWMax]
  w.f
  h.f
EndStructure


Macro px(x,y)
  pixeltable[x]\yPoint[y]
EndMacro




Procedure MixTwoColors(color1.l, color2.i, percent.f)
  r.f = ((Red(color1)*percent)/100) + ((Red(color2)*(100-percent)) / 100)
  g.f = ((Green(color1)*percent)/100) + ((Green(color2)*(100-percent)) / 100)
  b.f = ((Blue(color1)*percent)/100) + ((Blue(color2)*(100-percent)) / 100)
  ProcedureReturn RGB(r,g,b)
EndProcedure




Procedure.b LearnImage(file.s,*info.imageryinfo)

  *info\img = LoadImage(#PB_Any,file)
  If Not IsImage(*info\img) : ProcedureReturn #False : EndIf

  *info\w = ImageWidth(*info\img)
  *info\h = ImageHeight(*info\img)

  StartDrawing(ImageOutput(*info\img))
      For x = 0 To *info\w
          For y = 0 To *info\h
              *info\px(x,y) = Point(x,y)
          Next y
      Next x
  StopDrawing()

  ProcedureReturn #True

EndProcedure




;- PHOTOSHOP BLENDING MODES

Procedure.i Blend_Add(top.f,bottom.f)

  new.f = Defeat(#RGBFull, (bottom+top))

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Multiply(top.f,bottom.f)

  new.f = (bottom*top )/#RGBFull

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Screen(top.f,bottom.f)

  new.f = #RGBFull - ( ( #RGBFull - bottom ) * ( #RGBFull - top ) ) / #RGBFull

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Overlay(top.f,bottom.f)

  new.f
  If bottom < 128
      new = ( 2 * bottom * top ) / #RGBFull
  Else
      new = #RGBFull - ( 2 * ( #RGBFull - bottom ) * ( #RGBFull - top ) / #RGBFull )
  EndIf

  ProcedureReturn new

EndProcedure


;- PROBLEM WITH "SOFT LIGHT"
Procedure.i Blend_SoftLight1(top.f,bottom.f)

  ; ((L < 128) ? (2 * ((B >> 1) + 64)) * (L / 255): \
  ;                                     (255 - (2 * (255 - ((B >> 1) + 64)) * (255 - L) / 255))))

  ; ((top < 128) ? (2 * ((bottom >> 1) + 64)) * (top / #RGBFull): \
  ; (#RGBFull - (2 * (#RGBFull - ((bottom >> 1) + 64)) * (#RGBFull - top) / #RGBFull))))

  ; ((top < 128) ? (2 * ((bottom >> 1) + 64)) * (top / #RGBFull): \
  ; (#RGBFull - (2 * (#RGBFull - ((bottom >> 1) + 64)) * (#RGBFull - top) / #RGBFull))))

  new.f
  If top < 128
      new = ( 2 * bottom * top ) / #RGBFull
  Else
      new = #RGBFull - ( ( 2 * ( #RGBFull - bottom ) * ( #RGBFull - top ) ) / #RGBFull )
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_SoftLight2(top.f,bottom.f)

  a.f = bottom
  b.f = top

  c.f = a * b * Sqr(8)
  new.f = c + a * (#RGBFull-((#RGBFull-a)*(#RGBFull-b) * Sqr(8))-c) * Sqr(8)

  ProcedureReturn new

EndProcedure


Procedure.i Blend_SoftLight3(top.f,bottom.f)

  new.f

  If top > 128
      new = 255 - ((255-bottom) * (255-(top-128)) )
  Else
      new = bottom * (top+128)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_SoftLight(top.f,bottom.i)

  ; ((L < 128) ? (2 * ((B >> 1) + 64)) * (L / 255): \
  ;                                     (255 - (2 * (255 - ((B >> 1) + 64)) * (255 - L) / 255))))

  ; ((top < 128) ? (2 * ((bottom >> 1) + 64)) * (top / #RGBFull): \
  ; (#RGBFull - (2 * (#RGBFull - ((bottom >> 1) + 64)) * (#RGBFull - top) / #RGBFull))))

  ; ((top < 128) ? (2 * ((bottom >> 1) + 64)) * (top / #RGBFull): \
  ; (#RGBFull - (2 * (#RGBFull - ((bottom >> 1) + 64)) * (#RGBFull - top) / #RGBFull))))

  new.i
  If top < 128
      new =  (2 * ((bottom>>1) + 64 )) * (top/#RGBFull)
  Else
      new = #RGBFull - (2 * (#RGBFull - ((bottom>>1) + 64)) * (#RGBFull - top) / #RGBFull)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_HardLight(top.f,bottom.f)

  new.f
  If top < 128
      new = ( 2 * bottom * top ) / #RGBFull
  Else
      new = #RGBFull - ( ( 2 * ( #RGBFull - bottom ) * ( #RGBFull - top ) ) / #RGBFull )
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_ColorBurn(top.f,bottom.f)

  new.f
  If top<0
      new = 0
  Else
      new = Beat(#RGBFull - ((#RGBFull - bottom) * #RGBFull / top), 0)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_LinearBurn(top.f,bottom.f)

  new.f
  If top<0
      new = 0
  Else
      new = Beat(#RGBFull - ((#RGBFull - bottom) * #RGBFull / top), 0)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_ColorDodge(top.f,bottom.f)

  new.f = #RGBFull
  If top<#RGBFull
      new = Defeat(bottom*#RGBFull/(#RGBFull-top),#RGBFull)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Darken(top.f,bottom.f)

  new.f = Defeat(bottom,top)

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Lighten(top.f,bottom.f)

  new.f = Beat(bottom,top)

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Difference(top.f,bottom.f)

  new.f =Difference(bottom,top)

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Exclusion(top.f,bottom.f)

  new.f = #RGBFull - ( ( ( #RGBFull - bottom ) * ( #RGBFull - top ) / #RGBFull ) + ( bottom * top / #RGBFull ) )

  ProcedureReturn new

EndProcedure


Procedure.i Blend_LinearDodge(top.f,bottom.f)

  ProcedureReturn Blend_Add(top,bottom)

EndProcedure


;- PROBLEM WITH "LINEAR LIGHT"
Procedure.i Blend_LinearLight(top.f,bottom.f)

  new.f

  ; ATTEMPT 1
  If bottom < 128
      new = Blend_LinearBurn((2*bottom),top)
  Else
      new = Blend_LinearDodge((2*(bottom-128)),top)
  EndIf

  ; ATTEMPT 2
  If top>128
      new = bottom + (2*(top-128))
  Else
      new = bottom + (2*top) - 255
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_VividLight(top.f,bottom.f)

  ; (B < 128)? Blend_ColorBurn((2*B),L):ChannelBlend_ColorDodge((2*(B - 128)),L))

  new.f
  If bottom<128
      new = Blend_ColorBurn(2*bottom,top)
  Else
      new = Blend_ColorDodge(2*(bottom-128),top)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_PinLight(top.f,bottom.f)

  new.f

  If top > 128
      new = Beat(bottom,2*(top-128))
  Else
      new = Defeat(bottom,2*top)
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_HardMix(top.f,bottom.f)

  ; ((Blend_VividLight(B,L) < 128) ? 0:255)

  new.f = Blend_VividLight(bottom,top)
  If new<128
      new = 0
  Else
      new = #RGBFull
  EndIf

  ProcedureReturn new

EndProcedure










Enumeration
  ; do not change their order!
  #COLOR_RGB
  #COLOR_CMY
  #COLOR_HSV
  #COLOR_HSL
EndEnumeration

Structure Color
  StructureUnion
    r.f ; Red in RGB [0.0, 1.0]
    c.f ; Cyan in CMY [0.0, 1.0]
    h.f ; Hue in HSV/HSL [0.0, 360.0[
  EndStructureUnion
  StructureUnion
    g.f ; Green in RGB [0.0, 1.0]
    m.f ; Magenta in CMY [0.0, 1.0]
    s.f ; Saturation in HSV/HSL [0.0, 1.0]
  EndStructureUnion
  StructureUnion
    b.f ; Blue in RGB [0.0, 1.0]
    y.f ; Yellow in CMY [0.0, 1.0]
    v.f ; Value in HSV [0.0, 1.0]
    l.f ; Lightness in HSL [0.0, 1.0]
  EndStructureUnion
  type.l ; gives the type. One of #COLOR_RGB, #COLOR_CMY, #COLOR_HSV, #COLOR_HSL
EndStructure


ProcedureDLL.i ColorSetRGB(*c.Color, r.f, g.f, b.f) ; sets *c to the RGB-color given by r,g,b, each in range [0.0, 1.0] (no check is made) and returns *c
  *c\r = r
  *c\g = g
  *c\b = b
  *c\type = #COLOR_RGB

  ProcedureReturn *c
EndProcedure

ProcedureDLL.l ColorComplement(*c.Color) ; complements *c and returns *c
  If *c\type <= #COLOR_CMY
    ; if #COLOR_RGB or #COLOR_CMY
    *c\r = 1.0 - *c\r
    *c\g = 1.0 - *c\g
    *c\b = 1.0 - *c\b
  Else
    ; if #COLOR_HSV or #COLOR_HSL
    If *c\h >= 180.0
      *c\h - 180.0
    Else
      *c\h + 180.0
    EndIf
  EndIf
EndProcedure


;- some helper-proceudures
Procedure.f Max3F(a.f, b.f, c.f)
  If a > b
    If a > c
      ProcedureReturn a
    Else
      ProcedureReturn c
    EndIf
  Else
    If b > c
      ProcedureReturn b
    Else
      ProcedureReturn c
    EndIf
  EndIf
EndProcedure

Procedure.f Min3F(a.f, b.f, c.f)
  If a < b
    If a < c
      ProcedureReturn a
    Else
      ProcedureReturn c
    EndIf
  Else
    If b < c
      ProcedureReturn b
    Else
      ProcedureReturn c
    EndIf
  EndIf
EndProcedure


Procedure.f HSL2RGBHelper(q1.f, q2.f, h.f)
  If h >= 360.0
    h - 360.0
  ElseIf h < 0.0
    h + 360.0
  EndIf

  If h < 60.0
    ProcedureReturn q1+(q2-q1)*h/60.0
  ElseIf h < 180.0
    ProcedureReturn q2
  ElseIf h < 240.0
    ProcedureReturn q1+(q2-q1)*(240.0-h)/60.0
  Else
    ProcedureReturn q1
  EndIf
EndProcedure

ProcedureDLL.i HSL2RGB(*c.Color) ; converts HSL-color *c to RGB and returns *c. No check if HSL is made!
  Protected h.f, l.f, s.f
  Protected f.f, p1.f, p2.f, t.f
  Protected i.l

  h = *c\h
  l = *c\l
  s = *c\s

  If l<=0.5
    p2 = l*(1.0+s)
  Else
    p2 = l+s-l*s
  EndIf

  p1 = 2.0*l-p2

  If s=0.0
    ; it's a gray-tone
    *c\r = l
    *c\g = l
    *c\b = l
  Else
    *c\r = HSL2RGBHelper(p1, p2, h+120.0)
    *c\g = HSL2RGBHelper(p1, p2, h)
    *c\b = HSL2RGBHelper(p1, p2, h-120.0)
  EndIf

  *c\type = #COLOR_RGB

  ProcedureReturn *c
EndProcedure


ProcedureDLL.l ColorCopy(*c.Color) ; copies *c and returns *copy
  Protected *out = AllocateMemory(SizeOf(Color))
  CopyMemory(*c, *out, SizeOf(Color))
  ProcedureReturn *out
EndProcedure

ProcedureDLL.l Color2RGB(*c.Color) ; converts *c from any color-type to RGB and returns *c
  Select *c\type
    Case #COLOR_RGB : ProcedureReturn *c
    ;Case #COLOR_CMY : ProcedureReturn CMY2RGB(*c)
    ;Case #COLOR_HSV : ProcedureReturn HSV2RGB(*c)
    Case #COLOR_HSL : ProcedureReturn HSL2RGB(*c)
  EndSelect
EndProcedure

ProcedureDLL.l ColorRGB(*c.Color) ; converts an internal copy of *c to RGB and returns a Purebasic-RGB-colorcode same as returned by PB's RGB()
  Protected *cc.Color, rgb.l
  *cc = ColorCopy(*c)
  Color2RGB(*cc)
  rgb = RGB(255 * *cc\r, 255 * *cc\g, 255 * *cc\b)
  FreeMemory(*cc)
  ProcedureReturn rgb
EndProcedure


;- change color to HSL
ProcedureDLL.i RGB2HSL(*c.Color) ; converts RGB-color *c to HSL and returns *c. No check if RGB is made!
  Protected r.f, g.f, b.f, max.f, min.f, delta.f
  r = *c\r
  g = *c\g
  b = *c\b

  max = Max3F(r,g,b)
  min = Min3F(r,g,b)
  delta = max - min

  If delta <> 0.0
    ; get lightness
    *c\l = (max + min) / 2.0

    ; get saturation
    If *c\l <= 0.5
      *c\s = delta/(max+min)
    Else
      *c\s = delta/(2-max-min)
    EndIf

    ; get hue
    If r = max
      *c\h = (g-b)/delta
    ElseIf g = max
      *c\h = 2.0 + (b-r)/delta
    ElseIf b = max
      *c\h = 4.0 + (r-g)/delta
    EndIf

    *c\h * 60.0

    If *c\h<0.0
      *c\h + 360.0
    EndIf
  Else
    ; it's black
    *c\s = 0
    *c\h = 0 ; *c\h is even undefined
  EndIf

  *c\type = #COLOR_HSL

  ProcedureReturn *c
EndProcedure


Procedure.b PB2Color(pb.l,*c.Color)
  ColorSetRGB(*c,1/#RGBFull*Red(pb),1/#RGBFull*Green(pb),1/#RGBFull*Blue(pb))
EndProcedure




;- PHOTOSHOP MODES USING HSL CONVERSION

Procedure.i Blend_Hue(*top.Color,*bottom.Color)

  composite.Color
  composite\type = #COLOR_HSL
  composite\h = *top\h
  composite\s = *bottom\s
  composite\l = *bottom\l

  ProcedureReturn ColorRGB(@composite)

EndProcedure


Procedure.i Blend_Saturation(*top.Color,*bottom.Color)

  composite.Color
  composite\type = #COLOR_HSL
  composite\h = *bottom\h
  composite\s = *top\s
  composite\l = *bottom\l

  ProcedureReturn ColorRGB(@composite)

EndProcedure


Procedure.i Blend_Color(*top.Color,*bottom.Color)

  composite.Color
  composite\type = #COLOR_HSL
  composite\h = *top\h
  composite\s = *top\s
  composite\l = *bottom\l

  ProcedureReturn ColorRGB(@composite)

EndProcedure


;- PROBLEM WITH LUMINOSITY
Procedure.i Blend_Luminosity(*top.Color,*bottom.Color)

  composite.Color
  composite\type = #COLOR_HSL
  composite\h = *bottom\h
  composite\s = *bottom\s
  composite\l = *top\l

  ProcedureReturn ColorRGB(@composite)

EndProcedure




;- NON-PHOTOSHOP BLENDING MODES

Procedure.i Blend_Negation(top.f,bottom.f)
  ProcedureReturn #RGBFull-Abs(#RGBFull - bottom - top)
EndProcedure


Procedure.i Blend_Average(top.f,bottom.f)
  ProcedureReturn (bottom+top)/2
EndProcedure


Procedure.i Blend_Subtract(top.f,bottom.f)

  new.f = bottom+top-#RGBFull

  new = Beat(new,0)
  new = Defeat(new,#RGBFull)

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Reflect(top.f,bottom.f)

  new.f
  If bottom = #RGBFull
      new = bottom
  Else
      new = Defeat(#RGBFull, (top * top / (#RGBFull - bottom)))
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Glow(top.f,bottom.f)

  new.f
  If top = #RGBFull
      new = top
  Else
      new = Defeat(#RGBFull, (bottom * bottom / (#RGBFull - top)))
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Phoenix(top.f,bottom.f)

  new.f

  new = Defeat(bottom,top) - Beat(bottom,top) + #RGBFull

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Stamp(top.f,bottom.f)

  new.f
  c.f
  c = top + (2*top) - #RGBFull
  If c < 0
      new = 0
  ElseIf c > #RGBFull
      new = #RGBFull
  Else
      new = c
  EndIf

  ProcedureReturn new

EndProcedure


Procedure.i Blend_Freeze(top.f,bottom.f)

  If bottom = 0
      ProcedureReturn 0
  Else
      new.f = (#RGBFull - (Sqr(#RGBFull-top))) / bottom
      ProcedureReturn Beat(0,new)
  EndIf

EndProcedure




Macro BlendRGB(ProcName)

  r = ProcName(rt,rb)
  g = ProcName(gt,gb)
  b = ProcName(bt,bb)

EndMacro






;-
;- THE PROCEDURE

Procedure.i BlendPixel(pixeltop.i,pixelbottom.i,mode.b,opacity.f)

  If opacity<1
      ProcedureReturn pixelbottom
  EndIf

  rt.f = Red(pixeltop)
  gt.f = Green(pixeltop)
  bt.f = Blue(pixeltop)

  rb.f = Red(pixelbottom)
  gb.f = Green(pixelbottom)
  bb.f = Blue(pixelbottom)

  Select mode
      Case #Normal
          pixelblend = pixeltop
      Case #Hue, #Saturation, #Color, #Luminosity
          PB2Color(pixeltop,@tsplit.Color)
          PB2Color(pixelbottom,@bsplit.Color)
          ;ColorSetRGB(@bsplit.Color,1/#RGBFull*rb,1/#RGBFull*gb,1/#RGBFull*bb)

          RGB2HSL(@tsplit)
          RGB2HSL(@bsplit)
          ;Color_RgbToHls(pixelbottom,@bsplit.ColorAnalysis)
          Select mode
              Case #Hue
                  pixelblend = Blend_Hue(@tsplit,@bsplit)
              Case #Saturation
                  pixelblend = Blend_Saturation(@tsplit,@bsplit)
              Case #Color
                  pixelblend = Blend_Color(@tsplit,@bsplit)
              Case #Luminosity
                  pixelblend = Blend_Luminosity(@tsplit,@bsplit)
          EndSelect
      Default

          Select mode
              Case #Add, #LinearDodge
                  BlendRGB(Blend_Add)
              Case #Multiply
                  BlendRGB(Blend_Multiply)
              Case #Screen
                  BlendRGB(Blend_Screen)
              Case #Overlay
                  BlendRGB(Blend_Overlay)
              Case #SoftLight
                  BlendRGB(Blend_SoftLight)
              Case #HardLight
                  BlendRGB(Blend_HardLight)
              Case #VividLight
                  BlendRGB(Blend_VividLight)
              Case #ColorBurn
                  BlendRGB(Blend_ColorBurn)
              Case #LinearBurn
                  BlendRGB(Blend_LinearBurn)
              Case #ColorDodge
                  BlendRGB(Blend_ColorDodge)
              Case #Darken
                  BlendRGB(Blend_Darken)
              Case #Lighten
                  BlendRGB(Blend_Lighten)
              Case #Difference
                  BlendRGB(Blend_Difference)
              Case #Exclusion
                  BlendRGB(Blend_Exclusion)
              Case #HardMix
                  BlendRGB(Blend_HardMix)
              Case #PinLight
                  BlendRGB(Blend_PinLight)
              Case #LinearLight
                  BlendRGB(Blend_LinearLight)
              Case #Hue
                  BlendRGB(Blend_Hue)

              ; non-photoshop blend modes
              Case #Negation
                  BlendRGB(Blend_Negation)
              Case #Average
                  BlendRGB(Blend_Average)
              Case #Subtract
                  BlendRGB(Blend_Subtract)
              Case #Reflect
                  BlendRGB(Blend_Reflect)
              Case #Glow
                  BlendRGB(Blend_Glow)
              Case #Phoenix
                  BlendRGB(Blend_Phoenix)
              Case #Stamp
                  BlendRGB(Blend_Stamp)
              Case #Freeze
                  BlendRGB(Blend_Freeze)
          EndSelect

          pixelblend = RGB(r,g,b)

  EndSelect

  If opacity<100
      pixelblend = MixTwoColors(pixelblend,pixelbottom,opacity)
  EndIf

  ProcedureReturn pixelblend

EndProcedure




LearnImage(folder+"purple black.bmp",@img1.imageryinfo) ;- FILE FOR BACKGROUND IMAGE
LearnImage(folder+"85607236_o.jpg",@img2.imageryinfo) ;- FILE FOR TOP IMAGE (TO BE OVERLAID)

mixmode = #Hue
opacity = 100

StartDrawing(ImageOutput(img1\img))

    bx = 0
    by = 0;ih1/2

    For x = 0 To img2\w-1
        dx = Beat(0,bx+x)
        For y = 0 To img2\h-1
            dy = Beat(0,by+y)
            If dx=<img1\w And dy=<img1\h
                blend = BlendPixel(img2\px(x,y),img1\px(dx,dy),mixmode,opacity)
                Plot(dx,dy,blend)
            EndIf
        Next y
    Next x

StopDrawing()

;SetClipboardImage(img1\img)
ReportImage(img1\img,#True)

;-END
End

Seymour Clufley · Post by **Seymour Clufley** » Sun Feb 08, 2009 8:54 pm

I've updated the above code.

The BlendPixel procedure now has an opacity parameter (0-100) so you can overlay "by degree", as in Photoshop.

Soft Light now works a bit better than it did before. Linear Light is still a disaster.

I've implemented Froggerprogger's conversion code which works much better, allowing the remaining Photoshop modes to be added.

However they're far from perfect...

Saturation suffers from too much blue and too little red.
Color suffers from too little green.
Hue. The reds seem to be bang on. Greens are too bright. Blues are too dark.
Luminosity is the worst. There is too much green and far too much red. The blues seem to be pretty much correct.

I will continue to work on this and hopefully will deliver a final version tomorrow. I hope someone finds the code useful.

If I can find an algorithm for the Dissolve mode, I'll add that too. As far as I know that'll be all of Photoshop's modes.

Does anyone know any other blending algorithms that we could add to this?

Seymour Clufley · Post by **Seymour Clufley** » Fri Aug 21, 2009 7:13 am

I've updated these to work with the new CustomFilter drawing mode. Much faster, but opacity isn't included (1-100%, as in Photoshop, is included in the previous code).

Again, modes are included here that are not in Photoshop. I found them on a programmer's website back when I started this thread.

The modes Luminosity, Hue, Saturation and Color are not included here because, in their current state, they're unusable.

Code: Select all

Procedure.d Channel_ColorBurn(t.d,b.d)

  n.d
  If t<0
      n = 0
  Else
      n = Beat(#RGBFull - ((#RGBFull - b) * #RGBFull / t), 0)
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_ColorBurn(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_ColorBurn,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Add(t.d,b.d)

  ProcedureReturn Defeat(#RGBFull, (b+t))

EndProcedure
Procedure.i Blend_Add(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Add,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Multiply(t.d,b.d)

  ProcedureReturn (b*t)/#RGBFull

EndProcedure
Procedure.i Blend_Multiply(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Multiply,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Screen(t.d,b.d)

  ProcedureReturn #RGBFull - ( ( #RGBFull - b ) * ( #RGBFull - t ) ) / #RGBFull

EndProcedure
Procedure.i Blend_Screen(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Screen,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Exclusion(t.d,b.d)

  ProcedureReturn #RGBFull - ( ( ( #RGBFull - b ) * ( #RGBFull - t ) / #RGBFull ) + ( b * t / #RGBFull ) )

EndProcedure
Procedure.i Blend_Exclusion(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Exclusion,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Difference(t.d,b.d)

  ProcedureReturn Difference(t,b)

EndProcedure
Procedure.i Blend_Difference(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Difference,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Lighten(t.d,b.d)

  ProcedureReturn Beat(t,b)

EndProcedure
Procedure.i Blend_Lighten(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Lighten,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_Darken(t.d,b.d)

  ProcedureReturn Defeat(t,b)

EndProcedure
Procedure.i Blend_Darken(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_Darken,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_ColorDodge(t.d,b.d)

  n.d = #RGBFull
  If t<#RGBFull
      n = Defeat(b*#RGBFull/(#RGBFull-t),#RGBFull)
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_ColorDodge(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_ColorDodge,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_HardLight(t.d,b.d)

  n.d
  If t < 128
      n = ( 2 * b * t ) / #RGBFull
  Else
      n = #RGBFull - ( ( 2 * ( #RGBFull - b ) * ( #RGBFull - t ) ) / #RGBFull )
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_HardLight(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_HardLight,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_PinLight(t.d,b.d)

  n.d
  If t > 128
      n = Beat(b,2*(t-128))
  Else
      n = Defeat(b,2*t)
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_PinLight(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_PinLight,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_HardMix(t.d,b.d)

  n.d = Channel_VividLight(t,b)
  If n<128
      n = 0
  Else
      n = #RGBFull
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_HardMix(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_HardMix,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Here are some more, but these ones don't work perfectly:

Code: Select all

Procedure.d Channel_LinearBurn(t.d,b.d)

  n.d
  If t<0
      n = 0
  Else
      n = Beat(#RGBFull - ((#RGBFull - b) * #RGBFull / t), 0)
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_LinearBurn(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_LinearBurn,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

Procedure.d Channel_VividLight(t.d,b.d)

  n.d
  If b<128
      n = Channel_ColorBurn(2*b,t)
  Else
      n = Channel_ColorDodge(2*(b-128),t)
  EndIf

  ProcedureReturn n

EndProcedure
Procedure.i Blend_VividLight(x.i,y.i,topcol.i,bottomcol.i)

  CheckAlphaZero

  BlendRGB(Channel_VividLight,topcol,bottomcol)

  ProcedureReturn AlphaBlend(RGBA(nred,ngreen,nblue,alpha),bottomcol)

EndProcedure

You'll need these helper procedures:

Code: Select all

Procedure.d Beat(a.d,b.d)

  If a>b
      ProcedureReturn a
  Else
      ProcedureReturn b
  EndIf

EndProcedure


Procedure.d Defeat(a.d,b.d)

  If a<b
      ProcedureReturn a
  Else
      ProcedureReturn b
  EndIf

EndProcedure


Procedure.d Difference(a.d,b.d)

  If a=b
      ProcedureReturn 0
  EndIf

  ProcedureReturn Beat(a,b)-Defeat(a,b)

EndProcedure

Enjoy!

dige · Post by **dige** » Mon Mar 21, 2011 12:25 pm

Could'nt test the customfilter. What is CheckAlphaZero?

Seymour Clufley · Post by **Seymour Clufley** » Mon Mar 21, 2011 5:38 pm

That's just a macro to check whether the colour being overlaid (the top colour) has zero alpha. If it has, the procedure just returns the bottom colour (since nothing is being painted over it).

I'm sorry that I didn't include it.

[blendman] · Post by **[blendman]** » Mon Jul 04, 2011 11:24 pm

Hi

Your exemple works fine.

But how can I use this with some alpha chanel, and png image ?

Thank you very much.

Seymour Clufley · Post by **Seymour Clufley** » Tue Jul 05, 2011 7:34 am

I don't know if you can use these blending modes over a transparent image, even in Photoshop.

[blendman] · Post by **[blendman]** » Wed Jul 06, 2011 12:56 pm

Seymour Clufley wrote:I don't know if you can use these blending modes over a transparent image, even in Photoshop.

Hi

In photoshop, you can have some layers with transparents pixels, and blend them :

layer1 (the background) :

layer 2 (with transparent pixels):

blend mode in photoshop.
- normal :

- multiply

-overlay

-add :

I have tried to have the normal mode, and with a gadgetimage, it's easy.
So for the normal mode, can we use this simple technic ?

The code :

Code: Select all

Enumeration
  #Kbd_Add
  #Kbd_Subtract
  #kbd_up
  #kbd_down
EndEnumeration

;{ init
If UseJPEGImageDecoder() = 0 Or UsePNGImageDecoder() = 0 Or UseJPEGImageEncoder() = 0 Or UsePNGImageEncoder()=0 Or UseTGAImageDecoder()=0 Or UseTIFFImageDecoder() =0
  MessageRequester("Erreur", "Erreur de chargement des decoder images")
  End
EndIf
;}

;{ variables
Global quit.b, Event, size = 200, alpha_layer2.a=255
;}

Declare resizepicture()

Procedure event_()
  Event = WaitWindowEvent() ; This line waits until an event is received from Windows
  WindowID = EventWindow() ; The Window where the event is generated, can be used in the gadget procedures
  GadgetID = EventGadget() ; Is it a gadget event?
  EventType = EventType() ; The event type

  Select Event
    Case #PB_Event_CloseWindow
      quit=1

    Case #PB_Event_Menu
      Select EventMenu()

        Case #Kbd_Add
          size + 50
          resizepicture()

        Case #Kbd_Subtract
          If size > 50
            size - 50
            resizepicture()
          EndIf

        Case #Kbd_up
          If alpha_layer2<255
            alpha_layer2 +1
            resizepicture()
          EndIf
          SetWindowTitle(0,"Layer test - Alpha = "+Str(alpha_layer2))

        Case #kbd_down
          If alpha_layer2>1
            alpha_layer2 -1
            resizepicture()
          EndIf
          SetWindowTitle(0,"Layer test - Alpha = "+Str(alpha_layer2))
      EndSelect
  EndSelect
EndProcedure

Procedure open_win()
  If OpenWindow(0, 0,0, 400,400, "Layer test",  #PB_Window_SystemMenu | #PB_Window_MinimizeGadget | #PB_Window_MaximizeGadget | #PB_Window_SizeGadget | #PB_Window_TitleBar | #PB_Window_ScreenCentered | #PB_Window_WindowCentered)
    SmartWindowRefresh(0,1)

    LoadImage(0,"1.jpg")
    LoadImage(1,"2.png")
    CreateImage(2,800,800)
    CopyImage(1,3)

    AddKeyboardShortcut(0, #PB_Shortcut_Add, #Kbd_Add)
    AddKeyboardShortcut(0, #PB_Shortcut_Subtract, #Kbd_Subtract)
    AddKeyboardShortcut(0, #PB_Shortcut_Up, #Kbd_up)
    AddKeyboardShortcut(0, #PB_Shortcut_Down, #Kbd_down)

    ImageGadget(0, 0,0,size,size, ImageID(2),#PB_Image_Border|#PB_Image_Smooth)
    resizepicture()
  EndIf
EndProcedure

Procedure resizepicture()
  CopyImage(1,3)
  ResizeImage(3,size,size)
  CopyImage(0,4)
  ResizeImage(4,size,size)
  CopyImage(2,5)
  ResizeImage(5,size,size)
  StartDrawing(ImageOutput(5))
  DrawingMode(#PB_2DDrawing_AlphaChannel)
  Box(0,0,size,size,RGBA(15,15,15,255))
  DrawingMode(#PB_2DDrawing_Default)
  Box(0,0,size,size,RGB(255,255,255))
  DrawingMode(#PB_2DDrawing_AlphaBlend)
  DrawImage(ImageID(4),0,0)
  DrawAlphaImage(ImageID(3),0,0,alpha_layer2)
  StopDrawing()
  SetGadgetState(0,ImageID(5))
EndProcedure

open_win()
SaveImage(5,"save_newlayer.jpg")
Repeat
  event_()
Until quit = 1 Or Event = #PB_Event_CloseWindow

End

thank you

Seymour Clufley · Post by **Seymour Clufley** » Thu Jul 07, 2011 5:42 pm

Yes I know PS layers can be transparent. I was talking about what happens when you have a layer superimposed over a transparent area... for example, a black layer with "screen" mode superimposed over a transparent layer. I think that results in a black image.

As for your code, I've never used the canvas gadget so can't comment. You try it and see what works!

PureBasic Forums - English

Emulating Photoshop's blending modes

Emulating Photoshop's blending modes

Re: Emulating Photoshop's blending modes

Re: Emulating Photoshop's blending modes

Re: Emulating Photoshop's blending modes

Re: Emulating Photoshop's blending modes

Re: Emulating Photoshop's blending modes

Re: Emulating Photoshop's blending modes
